High Temperature RFID Tag for Industrial Identification
PPS HF Tags for Close-Range Identification
Questo high temperature RFID tag is a passive HF identification tag with a PPS housing. Its compact disc format is suitable for projects where tagged items pass close to a reader at an inspection point or processing station.
Three model families provide different diameters to fit the available installation space. The tag supplies an electronic identifier that connected software can associate with the item’s production, inspection or maintenance records.
Specifiche tecniche
| Parametro | Specifiche |
| Models | J-P15H / J-P24H / J-P25H |
| Alloggi | PPS — polyphenylene sulfide |
| Frequenza | 13,56 MHz |
| J-P15H diameter options | 15 / 18 / 20 mm |
| J-P24H diameter | 24.5 mm |
| J-P25H diameter | 25.5 mm |
| Opzioni relative ai chip | MIFARE Classic S50 / S70, ICODE SLI, NTAG213 / 215 / 216 |
| Protocol by chip | MIFARE Classic and NTAG: ISO/IEC 14443 Type A; ICODE SLI: ISO/IEC 15693 |
| Specified temperature range | −20°C to +180°C |
| Specified reading distance | 0-5 cm |
| Colore | Nero |
| Potenza | Passive; no battery |
Each chip option is a separate configuration. A reader must support the selected protocol and chip commands; matching the frequency alone does not establish compatibility.
High Temperature RFID Tracking Tags for Dishwashing Trays
One customer uses these high temperature RFID tracking tags on dishwashing trays. This provides a practical application example for identifying reusable items in a washing workflow.
For similar projects, evaluate the tag on the actual tray with the intended reader. Tray material, mounting position, washing conditions and attachment method should be checked before deployment.
Selecting and Installing High Temperature Asset Tags
Per high temperature asset tags, the installation needs to suit both the item and the process. Select the diameter according to the available space, then check the mounting surface and fixing method.
Metal near the antenna can affect reading. This product’s PPS housing does not, by itself, confirm suitability for direct metal mounting. Provide the proposed installation arrangement for assessment.
The attachment also needs to withstand the application. If adhesive is planned, check its temperature rating and suitability for the surface rather than relying only on the tag’s specification.
Sample Evaluation Before Deployment
Test samples with the reader and items that will be used in production. A useful evaluation includes:
- Reading at the intended position and orientation.
- Running the planned heating and cooling sequence.
- Checking identification at the required process stage.
- Inspecting the housing and attachment after repeated use.
Exposure duration, cycle count, nearby materials and reader placement all help define whether the selected configuration fits the project. A temperature range alone does not describe every process condition.
Discuss Your Installation Requirements
Send your reader model, preferred tag size, mounting surface, temperature profile and quantity. Include whether reading is required during heating or at another stage.
Our technical specialist can help review the configuration and arrange samples for evaluation.
E-mail il nostro team for samples and a quotation
Domande frequenti
The top questions about high temperature RFID tag
For smartphone NFC applications, select an NTAG configuration and check the phone, app and data format. Do not assume that every available chip works with every smartphone.
Keep the phone within its own permitted operating conditions.
Storage capacity and supported data operations depend on the selected chip.
For longer records, documents or inspection histories, keep the information in your software and use the tag identifier to retrieve it.
The supplied specifications do not establish an IP rating or resistance to particular chemicals.
For applications involving immersion, detergents, oils or solvents, provide the substance, concentration and exposure conditions for evaluation.
The MOQ is 500 pcs. Contact our team to confirm sample availability for compatibility and process testing.
